Description

• Single layer grid: All elements are located on the surface to be approximated.
• Double layer grid: Elements are organized in two layers parallel to each other at a certain distance apart. Each of the layers form a lattice of triangles, squares or hexagons in which the projection of the nodes in a layer may overlap or be displaced relative to each other. Diagonal bars connect the nodes of both layers in different directions in space. In this type of meshes, the elements are associated into three groups: upper cordon, cordon and cordon lower diagonal.
• Triple layer grid: Elements are placed in three parallel layers, linked by the diagonals. They are almost always flat.

Feature

Space frames are sometimes used in the chassis designs of automobiles and motorcycles. In both a space frame and a tube-frame chassis, the suspension, engine, and body panels are attached to a skeletal frame of tubes, and the body panels have little or no structural function. By contrast, in a unibody or monocoque design, the body serves as part of the structure.

Why the space frame structure stand out?

The flexibility and rigidity of space frame structure are immensely growing and in coming days will soon captivate the markets. Its aesthetics and design outlook makes it a worthy option. Apart from the pointers discussed above, in a series of upcoming article we will discuss on several other specifications and advantages of a Space Frame Structure.
